Coriolis mass flow meter „Universal Line“
- Sensor housing with removable cover
- Integrated heating
- High pressure design
- up to 900 bar
- Numerous special materials available
Development at the highest level
“High end” simulation technology enables the analysis and coupling of different models such as CSD (FEM), CFD, CEM, FSI, TFSI, saving much of the time that would have had to be invested in finding solutions in the past. This is our way in the future to solve highly complex measurement tasks for our customers.
By using the latest technologies, we are able to quickly identify and overcome application obstacles and provide optimal solutions for our customers.
Applications
- Metering of liquids and gases, viscous and corrosive media.
- Fields of application: Chemical, petrochemical, oil and gas, food, pharmaceutical. Dosing and loading systems, also in custody transfer.
Reliability
- Robust Design, immune to vibration effects and to pipeline generated stresses.
Special features
- Simultaneous measurement of mass flow rate, density, temperature and volume flow rate
- Numerous materials available
Integrated heating: steam, liquid, flange-to-flange, electric
- Process temperature: down to -90°C
- Process pressures: up to 900bar
- Housing: welded or screwed pressure-resistant
Technical data
Sensor
- Process connection: Flanges according to EN 1092, ASME B16.5, DIN2512, JIS, NPT, (other connections on request)
- Nominal pressure: PN 40, ASME Cl150 / 300 / 600 (standard) max. 900 bar (special version)
- Process temperature: -40 °C to +260 °C, -90°C (special version)
Ambient temperature
- Compact transmitter: -40°C to + 60°C / +80°C
- Remote transmitter: -40 °C to +100°C
- Protection class: IP 66 / IP 68 (EN60529)
Materials
- Wetted parts: 1.4404 (316 L) / 1.4571 (316 Ti), Hastelloy C-22, Hastelloy B-2, Monel, nickel, tantalum, other materials on request
- Housing:1.4301 (304 L)/Al to TM025, St 37.2/Al / 1.4301 TM050 Flameproof design welded or bolted
CE-Marking: Pressure Equipment Directive 97/23/EG
Measuring range 0.8 kg/h to 40,000 kg/h (liquid)
Transmitter UMC3
- Installation: Compact or remote mounted
- Power supply: 19 – 36 VDC, 24 VAC +/- 20%, 90 – 265 VAC
- Outputs: galvanically isolated
- Analogue: 2 x 0/4-20 mA
- Binary 1: active, potential free 24 V=, max. 200 mA
- Passive, optocoupler, Ui=30 V, Ii=200mA, Pi=3 W
- Frequency: 1 KHz
- Binary 2: Passive, optocoupler, Ui=30 V, Ii=200mA, Pi=3 W
- Status Passive, optocoupler, Ui=30 V, Ii=200mA, Pi=3 W
- Input binary: Counter reset
Ambient temperature: -20°C to +60°C/+80°C Protection class: IP 68 (EN60529)
Accuracy
- Liquid: ± 0.1%/ ± 0.05% of reading ± ZP stability
- Gas: ± 0.5% of measured value ± ZP stability
- Density (liquid): ± 0.005 g/cm³/± 0.003 g/cm³
- Volume:± 0,2% of reading ± ZP-Stability
Certificates and approval
Explosion protection (sensor) Sensor circuits intrinsically safe
DMT 01 ATEX E 149 X
II 1/2G EEx ia IIC T6-T2
(Approval for Zone 0 inside flow tubes)
CE-Marking: Pressure Equipment Directive 97/23/EG
- Explosion protection (converter) BVS 05 ATEX E 021 X
- Increased safety: EEx e (connection): II (1)2G Ex de[ia] [ia] IIC/IIB T6-T3
- Explosion proof: Ex d (connection): II (1)2G Ex d[ia] [ia] IIC/IIB T6-T3
- Signal outputs: intrinsically safe or non-intrinsically safe
NEPSI Approval Cert No. GYJ06477
CE-Marking: Explosion Protection Directive 2014/34/EU
EMC-Directive 89/336/EWG
Material certificates 3.1, 3.2 acc. DIN EN10204:2004
Metrology (Custody Transfer)
Communication
- HART®
- Profibus-PA
- Modbus RTU (RS 485)
